Tuofa China: Empowering Engineers with Precision CNC Machined Ti-10V-2Fe-3Al Components
In the realm of engineering, where performance and reliability are paramount, material selection plays a critical role in determining the success of your designs. For applications that demand exceptional strength, toughness, ductility, fracture toughness, and corrosion resistance, Titanium Ti-10V-2Fe-3Al Alloy (UNS R56410), also known as Ti-10-2-3, stands as a preeminent choice.
Potential of Ti-10-2-3: A Material Science Perspective
Ti-10-2-3 is a near-beta titanium alloy, meaning it has a microstructure composed primarily of beta phase titanium with a small amount of alpha phase titanium. This unique microstructure imparts the alloy with its exceptional combination of properties, making it an ideal material for a wide range of demanding applications.
![](/uploadfile/2024/07/26/2024072613420176rHLl.jpg)
Ti-10V-2Fe-3Al Properties
-
Exceptional Strength: Ti-10-2-3 boasts exceptional tensile strength and yield strength, enabling it to withstand extreme loads without compromising structural integrity. This makes it an ideal choice for components that must endure high stresses, such as aerospace components and automotive suspension parts.
-
Superior Toughness: This alloy exhibits remarkable resistance to crack propagation and fatigue, making it well-suited for applications that involve cyclic loading and harsh environments. This toughness ensures that Ti-10-2-3 components can withstand repeated stress without breaking or failing.
-
High Ductility: Ti-10-2-3 possesses exceptional ductility, allowing it to be formed and shaped into complex geometries without cracking or breaking. This ductility makes it suitable for applications that require intricate designs and precise machining.
-
Excellent Fracture Toughness: This alloy exhibits outstanding resistance to brittle fracture, making it a valuable material for applications that require high reliability and safety. This fracture toughness ensures that Ti-10-2-3 components can withstand sudden impacts without catastrophic failure.
-
Outstanding Corrosion Resistance: Ti-10-2-3 possesses exceptional resistance to a variety of corrosive environments, including seawater, chemicals, and high-temperature gases. This corrosion resistance makes it an ideal material for applications in marine environments, chemical processing, and power generation.
Table 1: Mechanical Properties of Ti-10V-2Fe-3Al Alloy (UNS R56410) at Room Temperature
Property |
Value |
Units |
Tensile Strength (Ultimate) |
1350-1500 |
MPa |
Yield Strength (0.2% Offset) |
1200-1350 |
MPa |
Elongation |
10-12 |
% |
Reduction in Area |
30-40 |
% |
Hardness (Rockwell B) |
34-38 |
HRB |
Modulus of Elasticity |
120-130 |
GPa |
Shear Modulus |
48-50 |
GPa |
Density |
4.43 |
g/cm³ |
Figure 1: Stress-Strain Curve for Ti-10V-2Fe-3Al Alloy (UNS R56410)
Comparison of Mechanical Properties of Ti-10V-2Fe-3Al Alloy (UNS R56410) with Other Materials
Property |
Ti-10V-2Fe-3Al |
6Al-4V Titanium |
Aluminum 6061-T6 |
Steel AISI 1018 |
Tensile Strength (Ultimate) |
1350-1500 MPa |
900-1050 MPa |
310 MPa |
650 MPa |
Yield Strength (0.2% Offset) |
1200-1350 MPa |
800-950 MPa |
270 MPa |
360 MPa |
Elongation |
10-12 % |
10-12 % |
12 % |
20 % |
Reduction in Area |
30-40 % |
30-40 % |
50 % |
60 % |
Hardness (Rockwell B) |
34-38 HRB |
32-36 HRB |
95 HRB |
121 HRB |
Modulus of Elasticity |
120-130 GPa |
115-125 GPa |
69 GPa |
207 GPa |
Shear Modulus |
48-50 GPa |
46-48 GPa |
26 GPa |
79 GPa |
Density |
4.43 g/cm³ |
4.43 g/cm³ |
2.7 g/cm³ |
7.85 g/cm³ |
As evident from the tables and charts above, Ti-10V-2Fe-3Al alloy offers a remarkable combination of strength, toughness, ductility, and fracture toughness compared to other commonly used materials. This makes it an ideal choice for a wide range of demanding applications, particularly in industries where weight reduction and high-performance are critical factors.
![](/uploadfile/2024/07/26/20240726134222qg1tZQ.jpg)
Benefits of Using Ti-10-2-3 for Engineers and Designers
-
Enhanced Performance: Ti-10-2-3 components can withstand higher stresses and loads without compromising structural integrity, leading to improved performance and reliability in demanding applications.
-
Weight Reduction: Ti-10-2-3 is significantly lighter than steel and other commonly used metals, making it an ideal choice for aerospace, automotive, and other weight-critical applications.
-
Corrosion Resistance: Ti-10-2-3 exhibits exceptional resistance to corrosion, making it suitable for harsh environments such as marine applications, chemical processing, and power generation.
-
Biocompatibility: Ti-10-2-3 is biocompatible, making it a valuable material for medical implants and surgical instruments.
-
Design Flexibility: Ti-10-2-3's high ductility allows it to be formed and shaped into complex geometries, enabling engineers to create innovative and lightweight designs.
Tuofa China: Your Trusted Partner for Precision Ti-10-2-3 CNC Machining
At Tuofa China, we recognize the intricacies of working with Ti-10-2-3 and are committed to providing you with the expertise and resources you need to achieve your engineering goals. Our team of experienced engineers and skilled machinists is equipped to handle the complexities of CNC machining Ti-10-2-3, ensuring that your components meet the most stringent specifications.
Why Choose Tuofa China for Your Ti-10-2-3 Needs?
-
Unparalleled Expertise: Our in-depth knowledge of Ti-10-2-3's properties and machining characteristics allows us to optimize our processes for maximum efficiency and precision.
-
State-of-the-Art CNC Machining Facilities: We employ the latest CNC machining technology to deliver consistently high-quality components with tight tolerances.
-
Rigorous Quality Control: Our multi-stage quality control procedures ensure that every component we produce meets your exacting standards.
-
Unwavering Commitment to Customer Satisfaction: We prioritize building long-lasting relationships with our customers and are dedicated to exceeding your expectations.
Transforming Your Ti-10-2-3 Designs into Reality
With Tuofa China as your partner, you can bring your most challenging designs to life using the exceptional properties of Ti-10-2-3. Our CNC machining capabilities enable us to produce a wide range of Ti-10-2-3 components, including:
Aerospace Components:
- Compressor discs
- Structural components
- Landing gear components
Automotive Components:
- Suspension components
- Brake components
- Drive shafts
Medical Implants:
- Surgical instruments
- Joint replacements
- Dental implants
Chemical Processing Equipment:
Marine Applications:
- Propellers
- Rudders
- Shafts
